Ürün Açıklamaları

Microduct ve Bundle Microduct lar GSM operatörlerinin şartnameleri ve IEC 60794-5 standardına göre üretilmektedir.

Dış Çap

İç Çap

Et Kalınlığı Ağırlık Makara Uzunluğu Makara Adedi
mm mm mm kg/m mt 40' Konteyner
20 16 2.0 0.462 1000 18
18 14 2.0 0.414 1000 18
16 12 2.0 0.364 2000 12
14 10 2.0 0.315 2000 18
12 8 2.0 0.265 2000 19
10 6 2.0 0.216 2000 24
7 3.5 1.75 0.135 2000 33

  • HAMMADDE Yüksek Yoğunluklu Polietilen (HDPE)
  • RENK Beyaz, Kırmızı, Yeşil
  • MARKALAMA Sanbor Microduct 3x14/10  PE-HD  01.01.2020  12.00  Mt 230

En uygun fiyatlar ve fiyat listesi için bizimle irtibata geçebilirsiniz.
Microduct Boruları

Sanbor Microduct Pipe is a bundle of pipes that is made up of several ducts. This pipe bundle is used in network applications such as Ftth (Fibre to the Home) They are suitable for direct buried installation and for inserting or pushing into cable shafts, into ducts or other pipe systems.

In Direct Buried (BD) applications, the Microducts will be directly buried, or bundled into Bundle configurations. Using a thicker walled Microduct is recommended to maintain the optimum fill ratios and have faster, easier installations.
In Direct Install (DI) applications, the Microduct or Bundle configurations will be placed inside an existing conduit, like an Over-Ride or populating an existing conduit. A thinner walled product is recommended where protection is provided by the existing conduit and space is more sensitive.

Characteristics of Microduct Pipes
• Highly resistant to crushing and external impacts
• Suitable for all environments (green or brown fields)
• Optional ribbed surface that enables cable blowing
• Reduced coefficient of friction
• Future proof, can accommodate more cables
• Cost-effective repairs of upgrades
• Requires less connections

Advantages of Microduct over Traditional Methods
• Microduct products are easily and quickly intalled in direct buried applications using minimally invasive micro-trenching equipment.
• Microduct pathways offer superior mechanical and enviromental protection for lightweight microfiber optical  cables, which can be easily installed using various air blowing techniques, or traditional cable pulling / pushing methods.
• Microduct patway systems offer telecom carriers increased flexibility de to the ease at which service laterals and drops can be reconfigured and installed as customer demand increases.


Bu ürüne ait teknik döküman bulunamadı.
Bu ürüne ait katalog bulunamadı.
Bu ürüne ait sertifika bulunamadı.
Ürün siparişleriniz için teklif isteyin, size dönelim
